VENTIS 108

PASSIVE POINT SOURCE

pole mounted

flying hardware

permanent installations

lightweight

Click on the image to zoom

Ventis 108 is a two-way point source crafted with a birch plywood cabinet scratch resistant enclosure and internal bracing.

Recommended amplifier 250W RMS. Rotatable horns for optimal horizontal or vertical sound dispersion angle. The 80° H x 50° V constant directivity of this point source 8" LF / 1" HF delivers in the listening area up to 121/126 dB SPL. Frequency response from 70Hz to 18kHz. Built-in passive crossover with soft-trip protection for the LF woofer and HF driver. Full suspension possibility through 4 M5 rigging points. The flexibility of Ventis 108 makes it as suitable for fixed installation as it is for use on the stage as FOH. Included one pocket handle. Equipped with 1.38" pole mount socket and a 45° sloped profile for unobtrusive placement on-stage as a monitor. B&C compression drivers and FBT’s own custom, long excursion woofers.

The Ventis series offers a wide range of loudspeakers built in birch plywood, as suitable for fixed installation as they are for use on the stage. The series comprises five point sources and two monitors available in either passive (Ventis 206, 115, 112, 110, 108, 115M and 112M) or bi-amplified versions (Ventis 206A, 115A, 112A, 110A,108A, 115MA and 112MA).ì

  • Configuration: 2 way
  • Low Frequency Woofer: 1 x 8'' - 2'' VC
  • High Frequency Driver: 1 x 1'' - 1.4'' VC
  • Recommended Amplifier: 250W RMS
  • Maximum SPL: 126dB
  • Material: Baltic birch plywood
Technical specifications
Code: 41213
Configuration: 2 way
Recommended amplifier: 250 W RMS
Long Term power: 125 W
Short term power: 500 W
Nominal impedance: 8 ohm
Frequency response: 70Hz - 18KHz -6dB
Low Frequency woofer: 8 - 2 coil inch
High frequency driver: 1 - 1.4 coil inch
Sensitivity (@1W/1m): 95 dB
Maximum SPL cont/peak: 120/126 dB
Dispersion: 80°x50° rotatable HxV
Crossover Frequency: 1.8 KHz
Recommended HP filter: 50Hz - 12-24db/oct
Recommended external filter: FBT DLM 26
Input connector: 2 x SPEAKON
Net Dimension (WxHxD): 274x500x300 / 10.8x19.7x11.8 mm/inch
Net Weight: 12.3 / 27.1 kg/lb
Accessories
VN-U108
AC-W568
