SHADOW 105T

MULTIPURPOSE 5” FULL RANGE 120W/8OHM - 112DB SPL

Click on the image to zoom

The Shadow family offers a wide range of high quality IP55 speakers, with the Shadow 105T being the most compact model. Despite its small size, this model is designed to provide top-notch voice and music performance in a variety of settings, whether indoor or outdoor.

The 5" full range speaker boasts a 120W/8ohm output, with a 2-way configuration that includes a high power 5" cone and 1" dome for high frequencies. The speaker also comes equipped with a 100V line transformer, with selectable 50W/25W power tapping, making it a versatile choice for different applications.

The die-cast aluminum wall bracket allows for multi-angle adjustment, with a ball/socket design and a security cable to ensure stability. Additionally, the speaker includes a 4 wires cable to select the desired power tapping. The water-stop grill provides 3 layers of protection, making it weather-resistant with an IP55 rating.

The Shadow compact model is finished in a standard grey color (RAL 7011), and it is perfect for installation in kiosks, water parks, cruise ships, queue lines, ticket counters, train platforms, sports venues, and many other spaces. Whether you're looking for a powerful outdoor speaker or a compact indoor option, the Shadow 105T is an excellent choice.

  • Configuration: 2 way
  • Low Frequency Woofer: 1 x 5'' - 1'' VC
  • High Frequency Driver: 1 x 1'' dome
  • Recommended Amplifier: 120W RMS
  • Maximum SPL: 112dB
  • Material: Polyethylene rotomolded


Technical specifications
Code: 36192
Configuration: 2 way
Recommended amplifier: 120 W RMS
Long Term power: 60 W
Short term power: 240 W
Nominal impedance: 8 ohm
Frequency response: 90Hz - 20KHz -6dB
Low Frequency woofer: 5 - 1 coil inch
High frequency driver: 1 - dome inch
Sensitivity (@1W/1m): 89 dB
Maximum SPL cont/peak: 190/112 dB
Dispersion: 100° HxV
Crossover Frequency: 3 KHz
Recommended HP filter: 70hz - 24dboct
Input connector: 4 wire cable
Net Dimension (WxHxD): 168x222x200 - 6.61x8.74x7.87 mm/inch
Net Weight: 3.5 / 7.7 kg/lb
