Mitus 215 has 2 B&C neodymium magnet woofers, each 380mm (15") in size, with a 75mm (3") voice coil. It also has a B&C HF driver that is 50mm (2") in size and has a 64mm (2.5") voice coil. The speaker has a maximum power of 1600 watts and a sound pressure level of 138dB at 4ohms. The HF horn is rotatable, with a coverage angle of 60°H x 40°V. The enclosure is made of birch plywood and has a scratch-resistant black paint finish. It also has 12 M10 fly points and two FBT design aluminum handles. This speaker is perfect for both live sound reinforcement applications and permanent installations.
MITUS 215
Passive Point Source
pole mounted
flying hardware
neodymium woofer
permanent installations
Click on the image to zoom
- Configuration: 2 way
- Low Frequency Woofer: 2 x 15'' - 3'' VC Neodymium
- High Frequency Driver: 1 x 2'' - 2.5'' VC Neodymium
- Recommended Amplifier: 1600W RMS
- Maximum SPL: 138dB
- Material: Baltic birch plywood
Technical specifications
Code:
35963
Configuration:
2 way
Recommended amplifier:
1600 W RMS
Long Term power:
800 W
Short term power:
2800 W
Nominal impedance:
4 ohm
Frequency response:
47Hz - 20Khz @-6dB
Low Frequency woofer:
2x15'' - 3'' VC neodymium
High frequency driver:
1x2'' - 3'' VC
Sensitivity (@1W/1m):
103 dB
Maximum SPL cont/peak:
134/138 dB
Dispersion:
60°x40° HxV
Crossover Frequency:
1.2 KHz
Recommended HP filter:
40hz - 24dboct
Recommended external filter:
FBT DSP Processor
Input connector:
2x speakon NL4M in & thru
Net Dimension (WxHxD):
493x1245x471 mm - 19.04x49x18.5 inch
Net Weight:
48 Kg / 105.82 Lb
