Mitus 210M is a passive stage monitor that includes two B&C custom neodymium magnet speakers, each measuring 250mm (10 inches) in diameter and featuring a 64mm (2.5 inch) voice coil. One of the loudspeakers is coaxial and includes a titanium compression driver with a 36mm (1.4 inch) exit and a 64mm (2.5 inch) voice coil. The monitor also includes a hi-grade passive internal crossover with "soft-trip" circuitry protection for both low and high frequencies. An amplifier with a recommended power output of 800 watts RMS at 4 ohms is suggested. The monitor has a 70° conical dispersion and is housed in a 15mm (5/8 inch) birch plywood enclosure with a scratch-resistant black paint finish. It also includes a 35mm (1.38 inch) stand socket and a back-side carrying handle. This monitor is ideal for live sound stage monitoring applications and can also be used as a front-of-house main PA speaker. Despite its features and capabilities, it is very lightweight, weighing only 19 kg.
MITUS 210M
PASSIVE STAGE MONITOR
neodymium woofer
permanent installations
lightweight
Click on the image to zoom
- Configuration: 2 way bass reflex with coaxial driver
- Low Frequency Woofer: 2 x 10'' - 2.5'' VC Neodymium coaxial
- High Frequency Driver: 1 x 1.4'' - 2.5'' VC titanium
- Recommended Amplifier: 800W RMS
- Maximum SPL: 132dB
- Material: Baltic birch plywood
Technical specifications
Code:
33216
Configuration:
2 way
Recommended amplifier:
800 W RMS
Long Term power:
400 W
Short Term Power:
1600 W
Nominal impedance:
8 ohm
Frequency response:
65Hz-20khz -6dB
Low Frequency woofer:
2x10 - 2.5 coil neodymium inch
High frequency driver:
1 x 1.14 - 2.5 coil inch
Sensitivity (@1W/1m):
100 dB
Maximum SPL cont/peak:
128/132 dB
Dispersion:
70° conical HxV
Crossover Frequency:
1.3 KHz
Recommended HP filter:
50hz - 24dboct
Input connector:
2 x speakon NL4MD-V in & thru
Net Dimension (WxHxD):
574x290x402 - 22.6x11.4x15.8 mm/inch
Download
